Wheeled lever for lifting very heavy and/or blocked cast iron covers using two PM 400 - 500 or 1000 in parallel or in special configuration two mechanical hooks.
The magnets PM500 are quickly placed on the cover surface assuring a very strong contact force, the kart hooks up the magnets and thanks to the long lever a normal size operator can deliver a very high lifting power that can open and move aside very blocked covers.
The central stud forms a contact triangle that during the lifting keeps firm the group kart/cover avoiding rocking or unwanted movements allowing the perfect control of operation. The kart can be completely disassembled to reduce the size, all is stored in a “cordura” sack for transport and integrity.
Completely decomposable to facilitate storage and transport. composed of: central column, two hooks and two sliding wheels and lever.
Adjustable lower strut for greater stability and a better control of the whole set.
It can also be customized on specific requests. Ask DOA for infos.
It can be use with two PM500 permanent magnet combined.
